SCENE 01 / POWER DISTRIBUTION SYSTEMS
Power Distribution Systems
Safe, reliable on-set power for film and TV production in Spain.
Here is how this works in practice. Power distribution systems safely route electrical today's from power packs or mains sources to lighting, camera, and production gear across a set. Pro distro boxes, cable runs, and breaker panels make sure balanced loads, proper grounding, and safe power delivery to each department.
Here is the short of it. We give power distribution systems configured for your production's electrical needs and set layout. Our team sets up with your gaffer and best boy to make sure the right capacity, cable lengths, and safety gear are in place for each location on your schedule.
Capabilities
Complete Power Solutions
From silent generators to comprehensive distribution systems, we provide the electrical infrastructure your production needs to run safely and reliably.
01
Generator Systems
- Super-silent generators
- Tow plant units
- Multi-gen coordination
- Battery backup systems
- Hybrid power solutions
Primary Power
02
Distribution Equipment
- Main distro boxes
- Sub-distribution units
- Lunchboxes & quads
- Stage pin systems
- European/US adapters
Safe Distribution
03
Cable Systems
- Feeder cable runs
- Extension cables
- Cable management
- Ramps & protection
- Connector systems
Complete Runs
04
Load Management
- Load calculations
- Circuit protection
- Power monitoring
- Phase balancing
- Safety systems
Safe Operation
On Location
Bates 60A and 100A spider boxes, CEE 32A and 63A European distribution through Camara Movil Madrid, Vantage Spain, and Welab Plus with heritage-zone silent-protocol staging at Alhambra and Alcázar
Here is how this works in practice. Power distribution systems in Spain run through Camara Movil Madrid, Vantage Spain Madrid and Barcelona, Welab Plus Barcelona. And Servicios Audiovisuales VSV alongside the lighting package allocation. Distribution inventory covers the full European 230V/50Hz standard plus US 120V cross-rental kit for incoming American shoots. Bates 60-amp and 100-amp spider boxes anchor the LA-default distribution chain. Paired with the European CEE 32-amp and 63-amp three-phase outlets that Spanish city mains and Mediapro and Filmax studio stages deliver natively.
Here is the short of it. Lunchbox quad-circuit Bates 60s and the smaller Bates 30s cover sub-distribution out to the person fixture positions, with stage-pin connectors at each junction. Honda EU2200i and EU7000is silent inverter power packs stage as the primary off-grid power for exterior commercial and documentary work. The EU7000is delivers 7000-watt steady with sub-58dB at 7 meters. Quiet enough for dialogue pickup with fitting baffle distance.
Here is the breakdown. Heritage-zone permits at the Alhambra Nasrid Palaces, Alcázar de Sevilla, Mezquita Córdoba, Toledo Cathedral. And Salamanca Plaza Mayor limit power packs placement and dictate explicit silent-protocol distribution. No Honda or Wacker Neuson power packs inside the historic perimeter. Full battery-powered Anton/Bauer Cine VCLX brick stacks for the AC-tied fixtures. And pre-OK'd cable routing through the Patronato or city heritage office. Cable runs use rubber-jacketed European H07RN-F 5-core feeder in 25mm² and 35mm² gauge with Stack-Magic and TwistLock connectors.
Here is what that looks like on the ground. Plus the LA-default 4/0 Cam-Lok feeder for incoming American shoots on the larger lighting blocks. Summer 40°C-plus Sevilla, Almería, and Madrid heat from July through August needs explicit cable de-rating. The H07RN-F 25mm² ampacity drops roughly 15 percent at ambient above 40°C and our gaffer factors that into load calculations. Wacker Neuson and Multiquip tow-behind 50 and 150 kVA fill the larger feature-set role.
FAQ
Power Distribution Expertise
What generator sizes do you provide?
We supply power packs from 20kVA to 500kVA including super-silent units for sound-sensitive shoots. Multi-power packs setups for larger power needs. Battery hybrid systems and tow plant units for many location needs.
How do you calculate power requirements?
We perform detailed load calculations based on your lighting package, camera and DIT needs, video village, and all other electrical needs. We factor in startup loads and give appropriate headroom for safe, reliable operation.
Can you provide power at historic locations?
Yes, we specialize in powering shoots at Spain's historic locations including châteaux, churches, and covered sites. We set up with venue needs, give appropriate cabling without damage, and make sure compliance with preservation guidelines.
Do you handle tie-ins to venue power?
We set up tie-ins to venue electrical systems where appropriate, working with licensed Spanish electricians and venue tech staff. We check ready power, arrange short-term connections, and make sure safe disconnection after your shoot.
What about power for remote locations?
For remote exteriors without mains power, we give complete power packs solutions including fuel management, noise mitigation, and multi-day operation. We plan logistics to make sure uninterrupted power across your shoot.
How do you ensure electrical safety on set?
All gear is PAT tested and well rated. We use RCD protection across, employ licensed electricians, and follow Spanish electrical safety rules. Detailed records and safety briefings make sure crew awareness.
